AIR-COOLED LIQUID CHILLERS WITH
INTEGRATED HYDRONIC MODULE
Air conditioning
30RBM/30RBP
Options
•
Low leaving water temperature down
to -6°C*
• Very low leaving water temperature
down to -12°C*
• High static fan for ducted application*
• Low noise level
• Very low noise level
• Grilles
• Side panels
• Electronic starter
• Winter operation for OAT down to
-10°C
• Winter operation for OAT down to
-20°C
• High ambient
• Evaporator frost protection
• Evaporator and hydronic module frost
protection
• Partial heat reclaim*
• Total Heat reclaim*
• Master/slave operation
• Suction and discharge valves
• Hydronic module with high-pressure
single or dual pump
• Hydronic module with low-pressure
single or dual pump
• Hydronic module with greenspeed®
single or dual pump
• Expansion tank
• Direct-expansion free-cooling (one or
two circuits)*
• Hydronic free-cooling*
• J-Bus, BacNet or LonTalk gateways
• Enviro-Shield, Super Enviro-Shield
coatings for MCHE coils
• Connection sleeve
• 230V electrical plug
• Touch Pilot operator interface
• Power Factor correction*
• Electric energy meter
Features
• Twelve sizes with nominal cooling capacities from 164 to 528 kW
• Aquasnap liquid chillers for commercial and industrial applications.
• 30RBM version with full load energy efficiency up to 3.1 (in accordance with
EN14511-3: 2013)
• 30RBP version with enhanced part-load energy efficiency using greenspeed®
condenser fans.
• 30RBP version with greenspeed® condenser fans for start-stop noise elimination.
• Extra energy savings through multiple options*: greenspeed® variable speed
pump, partial or total heat reclaim, partial or total free-cooling, electric energy
meter.
• All-aluminium micro-channel condenser (MCHE) and brazed plate heat exchanger
for low R-410A refrigerant charge.
• Night mode control.
• V-shaped condenser coils allowing protection against hail.
• Fast commissioning, as all units are systematically run tested before shipment.
• Leak-tight refrigerant circuit and reduced maintenance costs.
• Auto-adaptive control algorithm and automatic compressor unloading for
increased and efficiency optimization.
• Exceptional endurance tests for superior reliability.
\\MAINMENU\STATUS
CAPB_T
DEM_LIM
SP
CTRL_PNT
EMSTOP
0
100
4.2
-28.9
dsable
%
%
°C
°C
Circuit B Total Capacity
START/STOP
* Options available after official product
launch. Please contact your sales
representative for more information.
ENTER
PRO-DIALOG+
Pro-Dialog+ operator interface
46
Touch Pilot operator interface
