DUCTABLE Air-Cooled
Liquid Chillers
Air conditioning
30RBSY
Options
• Condenser with anti-corrosion posttreatment
• Condenser with pre-treated fins
• Suction air filters mounted on rails
• Coil protection grilles
• Very low noise level
• Soft starter (30RBSY 039-080)
• Frost protection down to -20°C
• High- and low-pressure single and
dual-pump hydronic modules with or
without expansion tank
• High-pressure variable-speed singleand dual-pump hydronic modules
with or without expansion tank
• Partial heat reclaim
• Enviro-Shield or Super Enviro-Shield
anti-corrosion protection for MCHE
heat exchangers
• JBus, BacNet and LonTalk gateways
• Evaporator screw or welded
connection sleeves
• Master/slave operation
• Remote interface
\\MAINMENU\STATUS
CAPB_T
DEM_LIM
SP
CTRL_PNT
EMSTOP
0
100
4.2
-28.9
dsable
%
%
°C
°C
Circuit B Total Capacity
START/STOP
ENTER
PRO-DIALOG+
Features
• Eleven sizes with nominal cooling capacities from 40 to 153 kW.
• Ductable Aquasnap liquid chillers for commercial or industrial applications. The
units include inverter fans to maximise EERs at all operating conditions.
• Latest technologi al innovations integrated: ozone-friendly refrigerant R-410A,
c
scroll compressors, low-noise fans made of a composite material, auto-adaptive
microprocessor control, electronic expansion valve and variable-speed pump
(option).
• Exceptionally high energy efficiency at part load - Eurovent energy efficiency
class A and B (in accordance with EN14511-3: 2013).
• All-aluminium micro-channel condenser (MCHE) for extra efficiency.
• Available static pressure of up to 240 Pa for sizes 039 to 060 and 090 to 120,
and up to 180 Pa for sizes 070 to 080 and 140 to 160.
• Low-noise scroll compressors with low vibration level.
• Vertical condenser coils with protection grilles (option on sizes 90-160).
• Low-noise Flying Bird IV fans, made of a composite material. Rigid fan
installation for reduced start-up noise.
• Small unit footprint and a low height (1330 mm), enclosed by easily removable
panels.
• Simplified electrical connections.
• Systematic operation test before shipment and quick-test function for stepby-step verification of the instruments, electrical components and motors.
• Several compressors connected in parallel.
• The electronic expansion device (EXV) allows operation at a lower condensing
pressure (EER optimisation), and dynamic superheat management optimises
the utilisation of the evaporator heat exchange surface.
• Maintenance-free scroll compressors and fast diagnosis of possible incidents
and their history via the Pro-Dialog+ control reduce maintenance costs.
• Leak-tight refrigerant circuit.
• Corrosion resistance tests, accelerated ageing test on compressor piping
and fan supports and transport simulation test on a vibrating table in the
laboratory.
Pro-Dialog+ operator interface
42
