air handling unitS
Air treatment
39HQ
Options
• 100% stainless steel
• Direct-drive fans
• All types of humidification systems,
including infrasonic
• Flat pack option for site assembly
• Heat recovery systems (run-around
coil, plate heat exchanger and
thermal wheels)
• Wide selection of standard accessories
• 316L stainless steel drain pan with
PVC wall lining in the outside air
inlet section and filter section
Features
High-efficiency
centrifugal fan
Special sorption heat
recovery wheels
Filters are easily
removable
Features
• Airovision is a modular construction that can be fully customised to provide
the required performance for any application.
• Special new casings encompass only high-quality components, including filters,
heat recovery systems, fan assemblies, cooling and heating coils, humidifiers
and attenuators.
• The Airovision range also pays special attention to air quality and reduction
of the energy required to cool, heat, humidify and supply the conditioned air.
• Airovision is available in a large selection of sizes and arrangements, suitable
for many different applications.
• Applications include leisure and event complexes, theatres, museums, libraries,
offices in companies and government institutions, shopping centres, supermarkets, department stores and educational establishments, as well as oil
drilling rigs, airports and cruise ships.
• In addition Airovision is also ideal in health care and in industries with stringent
hygiene requirements.
Environmentally sound
• No paint treatment required after the production process
• 100% recyclable components
• Low energy usage due to optimised component selection
• High-efficiency heat recovery systems available
Technical specification (in accordance with EN1886)
• Heat transfer factor class T2
• Thermal bridging factor TB 2
• Air tightness class B (L2)
• Mechanical strength class 1A (DI)
• Filter bypass leakage
- class F7 for standard slide-in construction
- class F9 for special slide-in construction
- class F9 for built-in construction
Generously sized
access doors
