air treatment modules
Air treatment
42GM
Options/accessories
• Customised product on request
Standard controls
NTC communicating controller
• Network communication
• Aquasmart Evolution system
compatible
• IAQ and DCV management
• Motorised blinds and lighting
control
Features
• One size with two-pipe plus electric heater or four-pipe coils, with an air flow
of 94 l/s, a cooling capacity of 2.2 kW and a heating capacity of 1.7 kW.
• Decentralised compact ducted chilled-water fan coil system, designed for
installation in plant rooms. This allows centralised service and maintenance.
• Reliable and efficient heating and cooling for office blocks and institutional
buildings.
• High efficiency EU6 filter.
• Extremely low sound level.
• The LEC (low energy consumption) fan motor assembly is available as standard.
This direct-drive motor is electronically commutated (EC motor), controlled by
a 0–10 V signal and allows precise, simple and quiet unit operation in a wide
range of rotational speeds in variation from the original speed.
• High-pressure centrifugal fans, compatible with air distribution systems up to
300 Pa.
• Compatible with the 35BD air diffuser range.
• Safe factory-installed electric heater for single or two-stage hot water heating.
• Available with demand control ventilation (DCV) and CO2 sensor.
• Can be equipped with a UV-PCO IAQ module.
• Low hydraulic pressure drop with a valve mounted, compatible with all chiller
pump kits.
• Quick installation with factory-installed options (controls, valves).
Aquasmart New System Manager
35BD linear diffuser (supply and return air)
