INDIVIDUAL COMFORT MODULES
Air treatment
42BJ
Options/accessories
• Factory-installed two- or four-way
valves
• High-efficiency filter
• Condensate pump
Standard controls
NTC communicating controller
• Network communication
• Aquasmart Evolution system
compatible
• IAQ and DCV management
• Motorised blinds and lighting
control
Features
• Three sizes with two-pipe, two-pipe plus electric heater or 4-pipe coils, with an
air flow range from 16 to 200l/s, a cooling capacity range from 0.5 to 4.9kW
and a heating capacity range from 0.5 to 5.8kW.
• Compact, U-shaped ducted chilled-water fan coil systems, designed for
installation above false ceilings in corridors.
• Reliable and economical cooling and heating for light commercial and office
applications.
• Includes a centrifugal fan with a low-energy consumption (LEC) motor. This
direct-drive motor is electronically commutated (EC motor). It is piloted by a
0-10 V signal that permits operation with a wide range of rotational speeds,
varying from the base setting and is precise, simple and quiet. It also includes
an air filter, a fresh air inlet with adjustable air quantity, a chilled-water
cooling coil and a hot-water heating coil and/or an electric resistance heater.
• U-shape model with inlet and outlet on the same side.
• Compatible with the 35BD air diffuser range.
• Low height of 270 mm (sizes 1.9 and 2.9).
• Extra low sound level in ducted air distribution system.
• High-pressure centrifugal fans, compatible with air distribution systems up to
300 Pa.
• High-efficiency F5 or F6 filter.
• Safe factory-installed electric heater for single or two-stage hot water heating.
• Low hydraulic pressure drop with a valve mounted, compatible with all chiller
pump kits.
• Quick installation with factory-installed options (controls, valves).
• Available with demand control ventilation (DCV) and CO2 sensor.
• Improved market competitiveness.
Aquasmart New System Manager
35BD linear diffuser (supply and return air)
112
