On these tabs you may manually adjust contrast curves for grayscale, RGB and CMYK images. Note
that the Administration Console has separate tabs for application of curves before and after application of Color
Management, located on two different tabs under the Color & Contrast node in the Admin Console.
When clicking Edit, you may choose the channel to adjust and click and drag the curve using the mouse.
You may also load or save Photoshop curves (*.amp, *.acv) directly from the curve edit window. Note
that RGB curves has an absolute black value in the lower-left corner of the diagram, while CMYK and
grayscale images have an absolute black value in the upper-right corner (similar to Photoshop).
When processing, the individual color curves are applied first, then the master curve.
Adjusting hue and saturation
Where: Channel | Color & Contrast | Hue & Saturation tab
On this tab you may change the hue, saturation and luminance either globally or of a specific color.
Image size and resizing options
Where: Channel | Image Size | Image Size tab
This page allows you to adjust image print size and/or preferences for physical resampling of image data.
