Roughers Carbide, HR( fine), R35 / 36 / 36 Al, DIN6527L, Harmony
- VHM-ULTRA grade of carbide for high performance- For roughing applications- 35 / 36 / 36 ° variable flute helix for chatter free milling- Optimised geometry for soft materials- CrN for copper and non-ferrous materials
HR
45 º +
15 º
Catalogue Code
E404
E405
Discount Group
B0210
B0210
Material
VHM-ULTRA
VHM-ULTRA
Surface Finish
CrN
CrN
Sutton Designation
Al
Al
Geometry
R35 / 36 / 36 HR
R35 / 36 / 36 HR
Shank Form( DIN 6535)
HA
HB
Shank Tolerance
h5
h5
Size Ref.
d 1
( h10)
l 1
l 2
d 2
z
Item #
Item #
1000
10.0
72
23
10
3
E404 1000
E405 1000
1200
12.0
83
28
12
3
E404 1200
E405 1200
1400
14.0
83
28
14
3
E404 1400
E405 1400
1600
16.0
92
34
16
3
E404 1600
E405 1600
1800
18.0
92
34
18
3
E404 1800
E405 1800
2000
20.0
104
42
20
3
E404 2000
E405 2000
2500
25.0
120
52
25
3
E404 2500
E405 2500
