SUTTON - katalog | KL-TECH s.r.o. | www.klte.cz SUTTON_katalog | Page 278

Slot Drills Carbide, 2 Flute, R30 N, DIN6527K
- For precision milling of slots & cavities
- S  uitable for materials up to 1600 N/mm 2
- TiAlN for longer tool life
+
12º
Catalogue Code
Discount Group
Material
Surface Finish
Sutton Designation
Geometry
Shank Form (DIN 6535)
Shank Tolerance
Size Ref.
d 1 (h10)
0200
0300
0400
0500
0600
0800
1000
1200
1600
2000
E501 E502 E503
B0208 B0210 B0210
VHM VHM VHM VHM
Brt Brt TiAlN TiAlN
N N N N
R30 R30 R30 R30
HA HB HA HB
h6 h6 h6 h6
l 1 l 2 d 2 z Item # Item # Item # Item #
50 3 6 2 50 4 6 2 54 5 6 2 54 6 6 2 54 7 6 2 58 9 8 2 66 11 10 2 72 12 12 2 82 16 16 2 92 20 20 2 E500 0200
E500 0300
E500 0400
E500 0500
E500 0600
E500 0800
E500 1000
E500 1200
E500 1600
E500 2000 E501 0200
E501 0300
E501 0400
E501 0500
E501 0600
E501 0800
E501 1000
E501 1200
E501 1600
E501 2000 E502 0200
E502 0300
E502 0400
E502 0500
E502 0600
E502 0800
E502 1000
E502 1200
E502 1600
E502 2000 E503 0200
E503 0300
E503 0400
E503 0500
E503 0600
E503 0800
E503 1000
E503 1200
E503 1600
E503 2000
www.klte.cz
2.0
3.0
4.0
5.0
6.0
8.0
10.0
12.0
16.0
20.0
E500 B0208
P
298
P
Steel
6
7
M
8
K
N
M
Stainless Steel
K
Cast Iron
S
H
9 10 11 12 13 14.1 14.2 14.3 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37.1 37.2 37.3 37.4 37.5 38.1 38.2 39.1 39.2 40 41
