DIN Taps G (BSPF), Straight Flute, N
d 1 TPI l 1 l 2 l 3 d 2 sq l 4 z drill ø
G 1/8
G 1/4
G 3/8
G 1/2
G 5/8
G 3/4
G 7/8
G 1
G 1-1/8
G 1-1/4
G 1-3/8
G 1-1/2
G 1-3/4
G 2 28
19
19
14
14
14
14
11
11
11
11
11
11
11 90 20 - 7.0 5.5 8 4 8.8
100 22 - 11.0 9.0 12 4 11.8
100 22 - 12.0 9.0 12 4 15.3
125 25 - 16.0 12.0 15 4 19.0
125 25 - 18.0 14.5 17 4 21.0
140 28 - 20.0 16.0 19 4 24.5
150 28 - 22.0 18.0 21 4 28.5
160 30 - 25.0 20.0 23 4 31.0
170 30 - 28.0 22.0 25 4 35.5
170 30 - 32.0 24.0 27 6 39.5
180 32 - 36.0 29.0 32 6 42.0
190 32 - 36.0 29.0 32 6 45.5
190 32 - 40.0 32.0 35 6 51.0
220 40 - 45.0 35.0 38 6 57.0
Size Ref.
T304 T305
D0402 D0406
HSSE HSSE
Brt TiN
N N
Form C / 2.5 x P Form C / 2.5 x P
ISO 228 ISO 228
Item # Item #
T304 0973
T304 1316
T304 1666
T304 2096
T304 2291
T304 2644
T304 3020
T304 3325
T304 3790
T304 4191
•
T304 4780
•
• T305 0973
T305 1316
T305 1666
T305 2096
T305 2291
T305 2644
T305 3020
T305 3325
•
•
•
•
•
•
www.klte.cz
0973
1316
1666
2096
2291
2644
3020
3325
3790
4191
4432
4780
5375
5961
Catalogue Code
Discount Group
Material
Surface Finish
Sutton Designation
Geometry
Chamfer
Limit & Nut Tolerance
- General Purpose use in materials up to approx. 1000 N/mm 2
- Through & blind holes
- Suitable machine operations
- Depths up to approx. 1 x d 1
P
Steel
6
7
M
8
M Non-Ferrous Metals
Stainless Steel
K
Cast Iron
K
N
S
H
9 10 11 12 13 14.1 14.2 14.3 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37.1 37.2 37.3 37.4 37.5 38.1 38.2 39.1 39.2 40 41
N
S
• Available on request as special manufacture. Subject to lead time.
Titanium & Super Alloys
H
Hard Materials
5
4
P
3
T304
T305
2
1
ISO
VDI 3323
• Optimal • Effective
