SUTTON - katalog | KL-TECH s.r.o. | www.klte.cz SUTTON_katalog | Page 234

DIN Taps UNC, Gun, VA PM
- PM-HSSE V3 offers superior tool life
- Use in stainless steels and high strength steels up to 850N/mm 2
- Through holes up to 3 x d 1
Size Ref.
d 1
0218
0284
0351
0417
0483
0635
TPI
56
40
32
32
24
20
d 1 TPI
l 1 l 2 l 3 d 2 sq l 4 z drill ø
45 9 12 2.8 2.1 5 3 1.85
56 11 18 3.5 2.7 6 3 2.35
56 12 20 4 3.0 6 3 2.85
63 13 21 4.5 3.4 6 3 3.50
70 16 25 6 4.9 8 3 3.90
80 19 30 7 5.5 8 3 5.10
T697
D0408
PM-HSSE V3
TiCN
VA PM
Special Relief
Form B / 4.5 x P
2BX
Item #
T697 0218
T697 0284
T697 0351
T697 0417
T697 0483
T697 0635
l 1 l 2 l 3 d 2 sq l 4 z drill ø Item #
90 22 - 6 4.9 8 3 6.60 100 24 - 7 5.5 8 3 8.00 110 28 - 9 7 10 4 10.80 110 32 - 12 9 12 4 13.50 T697 0794
T697 0953
T697 1270
T697 1588
P
254
Steel
4
M
Stainless Steel
5
6
7
M
8
K
Cast Iron
K
N
S
H
9 10 11 12 13 14.1 14.2 14.3 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37.1 37.2 37.3 37.4 37.5 38.1 38.2 39.1 39.2 40 41
N
3
T697
P
2
1
ISO
VDI 3323
Non-Ferrous Metals
S
Titanium & Super Alloys
H
Hard Materials
18
16
13
11
0794
0953
1270
1588
5/16
3/8
1/2
5/8
Size Ref.
• Optimal • Effective
www.klte.cz
# 2
# 4
# 6
# 8
# 10
1/4
Catalogue Code
Discount Group
Material
Surface Finish
Sutton Designation
Geometry
Chamfer
Limit & Nut Tolerance
