SUTTON - katalog | KL-TECH s.r.o. | www.klte.cz SUTTON_katalog | Page 137

ISO Taps UNF, Forming, Single Coolant Groove
- For cold forming of threads in materials with good flow characteristics
- Through or blind holes
- Depths up to approx. 1.5 x d 1
Size Ref.
d 1
0635
0794
0953
1270
TPI l 1 l 2 l 3 d 2 sq l 4 z Limit drill ø
28
24
24
20 66 19 25 6.30 5.00 7 - GH7 6.0
72 22 30 8.00 6.30 8 - GH7 7.5
80 24 33 10.00 8.00 9 - GH7 9.0
89 29 - 9.00 10 - GH8 12.1
7.10
T444
D0702
HSSE
Brt
N
Single Coolant Groove
Short
2B
Item #
T444 0635
T444 0794
T444 0953
T444 1270
