ISO Taps Metric Fine, Gun, N
- General purpose use
- Suitable for materials up to 1000N/mm 2
- Through holes
- Depths up to approx. 3 x d 1
Catalogue Code
Discount Group
Material
Surface Finish
Sutton Designation
Geometry
Chamfer
Limit & Nut Tolerance
Size Ref.
d 1
l 1 l 2 l 3 d 2 sq l 4 z drill ø
58 16 22 5.0 4.0 7 3 4.5
66 19 26 6.3 5.0 8 3 5.3
72 22 30 8.0 6.3 9 3 7.0
80 24 34 10.0 8.0 11 3 9.0
80 24 34 10.0 8.0 11 3 8.8
89 29 - 9.0 7.1 10 3 10.8
89 29 - 9.0 7.1 10 3 10.5
95 30 - 11.2 9.0 12 3 12.5
102 32 - 12.5 10.0 13 3 14.5
112 37 - 14.0 11.2 14 4 16.5
112 37 - 14.0 11.2 14 4 18.5
118 38 - 16.0 12.5 16 4 20.5
Pitch
MF 5 x 0.5
MF 6 x 0.75
MF 8 x 1
MF 10 x 1
MF 10 x 1.25
MF 12 x 1.25
MF 12 x 1.5
MF 14 x 1.5
MF 16 x 1.5
MF 18 x 1.5
MF 20 x 1.5
MF 22 x 1.5
T407 T408
D0702 D0706
HSSE HSSE HSSE
Brt Blu TiN
N N N
- - -
Intermediate Intermediate Intermediate
ISO 2 / 6H ISO 2 / 6H ISO 2 / 6H
Item # Item # Item #
•
•
T406 0805
•
T406 1006
•
T406 1207
•
•
•
•
• T407 0503
T407 0604
T407 0805
T407 1005
T407 1006
T407 1206
T407 1207
T407 1407
T407 1607
T407 1807
T407 2007
T407 2207 •
•
T408 0805
•
T408 1006
•
T408 1207
•
•
•
•
•
