ISO Taps Metric, Forming, Single Coolant Groove
- For cold forming of threads in materials with good flow characteristics
- Through or blind holes
- Depths up to approx. 1.5 x d 1
- TiN for longer tool life
d 1
Pitch
0250 M 2.5 x 0.45
0300 M 3 x 0.5
0350 M 3.5 x 0.6
0400 M 4 x 0.7
0500 M 5 x 0.8
0600 M 6 x 1
0800 M 8 x 1.25
1000 M 10 x 1.5
1200 M 12 x 1.75
l 2 l 3 d 2 sq l 4 z drill ø
10 - 2.80 2.24 5 - 2.3
48 11 15 3.15 2.50 5 - 2.8
50 13 17.5 3.55 2.80 5 - 3.2
53 13 18 4.00 3.15 6 - 3.7
58 16 22 5.00 4.00 7 - 4.6
66 19 26 6.30 5.00 8 - 5.5
72 22 30 8.00 6.30 9 - 7.4
80 24 34 10.00 8.00 11 - 9.3
89 29 - 9.00 7.10 10 - 11.2
80 24 34 10.00 8.00 11 - 9.5
89 29 - 9.00 10 - 11.4
7.00
T400
D0706
HSSE HSSE
Brt TiN
N N
Single Coolant Groove ≥ M3 Single Coolant Groove ≥ M3
Short Short
GH4 / 6H GH4 / 6H
Item # Item #
T399 0250
T399 0300
T399 0350
T399 0400
T399 0500
T399 0600
T399 0800
T399 1000
T399 1200 •
T400 0300
•
T400 0400
T400 0500
T400 0600
•
•
•
T637
T637 1005
T637 1206 •
•
www.klte.cz
1005 MF 10 x 1
1206 MF 12 x 1.25
l 1 45 T399 D0702
Size Ref.
Catalogue Code
Discount Group
Material
Surface Finish
Sutton Designation
Geometry
Chamfer
Limit & Nut Tolerance
P
P
Steel
M
Stainless Steel
7
M
8
K
Cast Iron
K
N
S
H
9 10 11 12 13 14.1 14.2 14.3 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37.1 37.2 37.3 37.4 37.5 38.1 38.2 39.1 39.2 40 41
N
Non-Ferrous Metals
S
• Available on request as special manufacture. Subject to lead time.
Titanium & Super Alloys
H
Hard Materials
6
5
4
3
T399
T400
2
1
ISO
VDI 3323
• Optimal • Effective
