Subaru WRX & WRX STI Manuals 2018 WRX & WRX STI Owner’s Manual | Page 423

Starting and operating/Reverse Automatic Braking System
7-71
! Obstacle detected and Alert level
Long proximity alert (object detected)
1) Green: 35 inches (90 cm) or more
Medium and close proximity alert (ap-
proaching the object and approaching
closer to the object)
1) Orange: 20 to 28 inches (50 to 70 cm)
2) Yellow: 28 to 35 inches (70 to 90 cm)
Closest proximity alert (too close to the
object)
1) Red: 20 inches (50 cm) or less
When an object is detected in the rever-
sing direction, the range of detected object
will be shown on the multi-function display
(color LCD).
A warning alarm will sound and, depend-
ing on the speed, either torque control to
generate engine braking or automatic
braking will be applied.
– CONTINUED –
