3-50

Instruments and controls/Multi function display

& Basic operation

the road and could result in an
accident.
The multi function display has the following functions.
Description

Page

Displays useful messages,
such as warning information,
etc.

3-53

Displays basic screens (e.g.
fuel consumption screen, etc.)

3-53

Sets and adjusts maintenance
notification

3-81

Registers driving history

3-84

Sets and customizes car operation

3-85

Reverse Automatic Braking
system (if equipped)

7-64

Control switch
1) Up (select)
2) ENTER (push)
3) Down (select)

By operating “ ” or “ ” of the control
switch, the screens and selection items
can be switched. When the
button is
pushed, the item can be selected and set.

Also, the multi function display can also be
used to set and initialize the multi function
display itself.

& Welcome screen
Multi function display
1) Outside temperature indicator
2) Top display (For the display setting, refer
to “Top display setting” F3-73.)
3) Clock
4) Driving information display (For the displayed contents, refer to “Basic screens”
F3-53.)

When the door is unlocked and the
driver’s door is closed, the welcome
screen will appear for a short time.
