Instruments and controls/Multi function display

“On” to activate the buzzer. Select “Off” to
deactivate the buzzer.
! BSD/RCTA (if equipped)
After entering the “BSD/RCTA” menu,
select the “Warning Volume” menu. You
can set the volume of the warning buzzer
for RCTA (Rear Cross Traffic Alert). You
can select “Max”, “Mid”, “Min” or “Off”.
! RAB (models with EyeSight system)
After entering the “RAB” menu, select one
of the following menus.

NOTE
For models with Reverse Automatic
Braking system, refer to “Reverse
Automatic Braking System” F7-64.
! Warning Volume
The volume of the warning sound that is
activated when the Reverse Automatic
Braking system is in operation can be set
in 3 stages (“Max”, “Mid” and “Min”).
! Sonar Audible Alarm
The Reverse Automatic Braking system is
equipped with a function that emits a
warning sound when the system operates.
The function can be activated or deactivated. Select “On” to set the warning
sound to active. Select “Off” to set the

warning sound to inactive.
! Default Settings
Select “Yes” to use the menu screen to
restore customized settings to the factory
default settings. Select “No” to return to
the previous screen without restoring to
the factory default settings.

3-49

Multi function display
NOTE
. Illustrations show the display for
U.S.-spec. models as an example. For
models other than U.S.-spec. models,
elements in the illustrations (such as
the display indication and measurement unit) may be different than the
ones for U.S.-spec. models.
. When the vehicle is in motion,
certain functions and selections may
not be available.
. The images shown in this Owner’s
Manual are sample images. The actual
images may vary depending on the
destinations and specifications.

WARNING
Always pay adequate attention to
safe driving when operating the
multi function display while the
vehicle is in motion. When operation
of the multi function display is
disturbing your awareness and ability to concentrate on driving, stop
the vehicle in a safe place before
performing operations on the
screen. Also, do not concentrate
on the display while driving. Doing
so may cause you to look away from
– CONTINUED –
