6-16

Interior equipment/Rear view camera

! When there is an upward slope at
the back

CAUTION
. When moving backward, always
check the back with your eyes
without relying on the help lines.
. The actual position may be different from the indication of the
help lines.
. Differences may occur due to
number of passengers or loaded
cargo.
. When the vehicle is on a slope or
when the vehicle is inclined
against the road, the indication
is different from the actual position.
. Be sure to observe the displayed
warning message of “Check Surroundings Before Backing Up”.
! Difference between screen image
and actual road
The distance markers show the distance
for a level road when the vehicle is not
loaded. It may be different from the actual
distance depending on the loading conditions or road conditions.

1)

3 feet (1 m)

The distance on the screen looks farther
than the actual distance.

! When there is a downward slope
at the back

1)

3 feet (1 m)

The distance on the screen looks nearer
than the actual distance.

NOTE
When cargo is loaded, the rear view
distance on the screen looks farther
than the actual distance as in an
upward slope.
