Instruments and controls/Multi function display

3-49

& Basic operation

NOTE
Control switch
1) Up (select)
2) ENTER (push)
3) Down (select)

By operating “ ” or “ ” of the control
switch, the screens and selection items
can be switched. When the
button is
pushed, the item can be selected and set.

& Welcome screen
Multi function display
1) Outside temperature indicator
2) Top display (For the display setting, refer
to “Top display setting” F3-71.)
3) Clock
4) Driving information display (For the displayed contents, refer to “Basic screens”
F3-52.)

When the door is unlocked and the
driver’s door is closed, the welcome
screen will appear for a short time.

. The welcome screen will disappear
when the ignition switch is turned to
the “ON” position while the welcome
screen is displayed.
. The welcome screen can be set to
on or off. For details, refer to “Bypass
screen setting” F3-77.
. For a certain period of time after the
welcome screen has once appeared, it
may not appear again even when the
driver’s door is closed again. This does
not indicate a malfunction.

– CONTINUED –
