Subaru WRX & WRX STI Manuals 2016 WRX & WRX STI Owner’s Manual | Page 177

3-48

Instruments and controls/Multi function display

“On” to activate the buzzer. Select “Off” to
deactivate the buzzer.
! BSD/RCTA (if equipped)
After entering the “BSD/RCTA” menu,
select the “Warning Volume” menu. You
can set the volume of the warning buzzer
that sounds when the BSD/RCTA is in
use. You can select “Max”, “Mid”, “Min” or
“Off”.
! Default Settings
Select “Yes” to use the menu screen to
restore customized settings to the factory
default settings. Select “No” to return to
the previous screen without restoring to
the factory default settings.

Multi function display
NOTE
. Illustrations show the display for
U.S.-spec. models as an example. For
models other than U.S.-spec. models,
elements in the illustrations (such as
the display indication and measurement unit) may be different than the
ones for U.S.-spec. models.
. When the vehicle is in motion,
certain functions and selections may
not be available.
. The images shown in this Owner’s
Manual are sample images. The actual
images may vary depending on the
destinations and specifications.

WARNING
Always pay adequate attention to
safe driving when operating the
multi function display while the
vehicle is in motion. When operation
of the multi function display is
disturbing your awareness and ability to concentrate on driving, stop
the vehicle in a safe place before
performing operations on the
screen. Also, do not concentrate
on the display while driving. Doing
so may cause you to look away from

the road and could result in an
accident.
The multi function display has the following functions.
Description

Page

Displays useful messages, such
as warning information, etc.

3-52

Displays basic screens (e.g. fuel
consumption screen, etc.)

3-52

Sets and adjusts maintenance
notification

3-79

Registers driving history

3-82

Sets and customizes car operation

3-83

Also, the multi function display can also be
used to set and initialize the multi function
display itself.
