Instruments and controls/Warning and indicator lights

mode. For details, refer to “Driver’s Control Center Differential (C.DIFF/DCCD)
(STI)” F7-19.

& Driver’s control center differential indicator and warning
(STI)

! Driver’s control center differential auto [+] indicator
(STI)

3-33

! Indicator

When the AUTO [+] mode is set, the
AUTO [+] indicator appears.
For details, refer to “Driver’s Control
Center Differential (C.DIFF/DCCD) (STI)”
F7-19.
! Driver’s control center differential auto [−] indicator
(STI)
When the AUTO [−] mode is set, the
AUTO [−] indicator appears.
For details, refer to “Driver’s Control
Center Differential (C.DIFF/DCCD) (STI)”
F7-19.

When you select the manual mode of the
driver’s control center differential, the
initial limited slip differential (LSD) torque
that is currently selected for the center
differential is indicated by the illumination
of these indicator.

! Warning indicator

All the indicators will flash in the event that
the driver’s control center differential has a
malfunction. Have the vehicle inspected
by your SUBARU dealer. For details, refer
to “Driver’s Control Center Differential (C.
DIFF/DCCD) (STI)” F7-19.
If a malfunction occurs in the vehicle (for
example, when the rear differential oil
temperature warning light illuminates or
the AWD warning light blinks), all of the
indicators may disappear and the setting
value for the initial limited slip differential
(LSD) torque of the driver’s control center
differential (C.DIFF/DCCD) may be cancelled. However, it does not indicate a
malfunction of the C.DIFF/DCCD itself.

– CONTINUED –
