3-12

Instruments and controls/REV indicator light and buzzer (STI)

between the average rate of fuel consumption since the trip meter was last
reset and the current rate of fuel consumption.

REV indicator light and buzzer (STI)

The ECO gauge indicates the current fuel
efficiency as shown in the following chart.
Needle position

Displayed
unit

“+” side

“-” side

MPG

Better

Poorer

l/100km

Poorer

Better

km/l

Better

Poorer

NOTE
. The ECO gauge shows only an
approximate indication.
. After resetting the trip meter, the
average rate of fuel consumption is not
shown until driving 0.6 mile (1 km).
Until that time, the ECO gauge does not
operate.

1)

REV indicator light

The REV alarm system has the following
functions.
. When the engine speed reaches the
level that was previously set, the REV
indicator light illuminates to inform you. At
this time, a buzzer also sounds if the
buzzer setting is activated.
. Whenever the engine speed enters the
red zone of the tachometer, the REV
indicator light flashes.

NOTE
Even if the REV alarm system is not set,
the REV indicator light will flash when-

ever the engine speed enters the red
zone of the tachometer.
To change the REV indicator settings,
perform the procedures described in “REV
settings (STI)” F3-44.
