Instruments and controls/Meters and gauges

NOTE

the fuel in the fuel tank.
. If the refuel amount is less than
approximately 4.0 US gal (15 liters, 3.3
Imp gal), it may take some time until the
fuel gauge indication stabilizes.

& Temperature gauge

3-11

Engine operation is optimum with the
engine coolant at this temperature range
and high revving operation when the
engine is not warmed up enough should
be avoided.

CAUTION
If the pointer exceeds the normal
operating range, safely stop the
vehicle as soon as possible.
Refer to “Engine overheating” F911.

. You will see the “
” sign in the fuel
gauge.
This indicates that the fuel filler door
(lid) is located on the right side of the
vehicle.
. When you have refueled, the fuel
gauge indicates the amount in the fuel
tank after starting the engine. Also, it
may take some time until the fuel
gauge indication stabilizes.
. The gauge indicates only an approximate amount of fuel remaining in the
tank. Use this indication only as a
guide.
. If you refuel while the ignition switch
is in the “ON” position, the fuel gauge
may not indicate the correct amount of

& ECO gauge

1)

Normal operating range

The temperature gauge shows engine
coolant temperature when the ignition
switch is in the “ON” position.
The coolant temperature will vary in
accordance with the outside temperature
and driving conditions.
We recommend that you drive moderately
until the pointer of the temperature gauge
reaches near the middle of the range.

The unit displayed varies depending on the
models.

The ECO gauge shows the difference
– CONTINUED –
