Instruments and controls

& Odometer/Trip meter

nation after the driver’s door is opened,
the illumination will be turned off.
. Even during the gradual turning off
after the ignition switch is turned to the
“LOCK” position, if the ignition switch
is turned to the “ON” position, the
combination meter illuminate as usual.
To change the setting:
1. Turn the ignition switch to the “LOCK”
or “Acc” position.

*: “ ” or “
”, and “
” or “
” cannot
be displayed when the ignition switch is
in the “ON” position.
3. To change the current setting, press
the trip knob for at least 2 seconds.
: Activated
: Deactivated

NOTE
2. Press the trip knob to show “
” or
“
” on the odometer and trip meter
display. The display can be switched as
shown in the following illustration by
pressing the trip knob.

3-7

The initial illumination setting of the
meter/gauge needles of your vehicle
has been set for activation “
” at the
time of shipment from the factory.

& Speedometer
The speedometer shows the vehicle
speed.

1)

Trip knob

This meter displays the odometer and two
trip meters when the ignition switch is in
the “LOCK”, “Acc” or “ON” position.
If you press the trip knob when the ignition
switch is in the “LOCK” position, the
odometer/trip meter will light up. It is
possible to switch the indications while
the odometer/trip meter is lit up. If you do
not press the trip knob within 10 seconds
of illumination of the odometer/trip meter,
the odometer/trip meter will turn off.
The display can be switched as shown
below by pressing the trip knob.

– CONTINUED –
