10. To remove the child restraint system, press the release button on the seatbelt buckle and allow the belt to retract completely. The belt will return to the ELR mode. |
1 |
||||||
|
7. Before having a child sit in the child restraint system, try to move it back and forth and right and left to check if it is firmly secured. Sometimes a child restraint system can be more firmly secured by pushing it down into the seat cushion and then tightening the seatbelt. It should not be possible to move the child restraint system more than 1 in( 2.5 cm) in any direction along the seatbelt path.
8. Pull at the shoulder portion of the belt to confirm that it cannot be pulled out( ALR properly functioning).
|
9. Latch the top tether hook onto the tether anchorage that is located behind the rear seat and tighten the top tether firmly. For additional instructions, refer to“ Top Tether Anchorages” FP70. |
NOTE
When the child restraint system is no longer in use, remove it and restore the ELR function of the retractor. That function is restored by allowing the seatbelt to retract fully.
|
& Installing a Booster Seat or Booster Cushion s01ag05
WARNING
NEVER INSTALL A BOOSTER SEAT / CUSHION ON THE FRONT PASSEN- GER’ S SEAT IF THE FRONT PAS- SENGER’ S FRONTAL AIRBAG ON INDICATOR ILLUMINATES. DOING SO RISKS SERIOUS INJURY OR DEATH TO THE CHILD BY PLACING THE CHILD’ S HEAD TOO CLOSE TO THE SRS AIRBAG.
|
Seat, Seatbelt and SRS Airbags |
|||
– CONTINUED – |
