NOTE
When the settings cannot be changed, the ON / OFF setting key will be grayed out.
Also, the following settings can be changed by operating the center information display.
. Warning volume. Sonar Audible Alarm
For details, refer to“ Car settings” FP200.
& RAB Warning Indicator
1 RAB malfunction message 2 RAB warning indicator
s07bn07
If the Reverse Automatic Braking( RAB) system malfunctions, the above indicator illuminates on the combination meter.
|
Contact the nearest SUBARU dealer for details.
& Handling of the Sonar Sensors s07bn06
The 4 sonar sensors are located in the rear bumper. To ensure the proper operation of the Reverse Automatic Braking( RAB) system, observe the following precautions.
. Do not affix any stickers or other items on the sonar sensor or the rear bumper surface.
. Always keep the sonar sensor and the rear bumper surface clean.
. Do not modify rear bumper.. Do not paint the rear bumper.. Do not apply high pressure water to the
|
sonar sensors with a high pressure carwashing machine.
. Do not apply strong impacts to the rear bumper. If a sensor becomes misaligned, a system malfunction may occur, including inability to detect objects in the reversing direction. If any strong impact is applied to the rear bumper, contact a SUBARU dealer to have the system inspected.
. Do not disassemble the sonar sensors.
NOTE
If the sonar sensors require repair or replacement, or if the area of the rear bumper near the sonar sensors requires repair, paintwork or replacement, contact your SUBARU dealer for assistance.
|
7
Starting and Operating
|
