1 Status Indicators
Within 5 seconds after programming a new HomeLink ® button, both of HomeLink’ s garage door status indicators will flash rapidly green indicating that the garage door two-way communication has been enabled. If your garage door status indicators flashed, two-way communication programming is complete.
If the garage door status indicators do not flash, additional HomeLink ® information and programming videos can be found
|
1 Status Indicator
Recall and display( at any time) the last recorded garage door status message communicated to HomeLink ® by simultaneously pressing HomeLink ® buttons 1 and 2 for 2 seconds. HomeLink ® will display the last recorded status for 3 seconds.
If two-way communication programming is successful, HomeLink ® will display the status of your garage door opener with arrow indicators( see below).
|
1 Garage Door Opener CLOSING( Blinking Orange)
2 Garage Door Opener CLOSED( Solid Green)
3 Garage Door Opener OPENING( Blinking Orange)
4 Garage Door Opener OPENED( Solid Green)
! Certification s03ap070416
In the event that there are still programming difficulties or questions, additional HomeLink ® information and programming videos can be found at www. HomeLink. com, www. youtube. com / HomeLinkGentex, or by calling the toll-free HomeLink-hotline at 1-800-355-3515.
– CONTINUED –
|
