! Gate Operator / Canadian Programming s03ap070410
Canadian radio-frequency laws require transmitter remote signals to“ time-out”( or quit) after several seconds of transmission, which may not be long enough for HomeLink ® to pick up the signal during programming. Similar to this Canadian law, some U. S. gate operators are designed to“ time-out” in the same manner. The indicator LED on the hand-held remote will go off when the device times out, indicating that it has finished transmitting.
If you live in Canada or you are having difficulties programming a gate operator or garage door opener by using the programming procedures, replace“ Programming a New HomeLink ® button” step 3 with the following:
While the HomeLink ® indicator light is flashing orange, press and release(“ cycle”) your device’ s hand-held remote every two seconds until the HomeLink ® indicator light changes from orange to green. You may now release the hand-held remote button.
NOTE
If programming a garage door opener or gate operator, it is advised to unplug the device during the“ cycling” process to prevent possible overheating.
Proceed with“ Programming a New HomeLink ® button” step 4 to complete.
! Using HomeLink ® s03ap070411
To operate, simply press and release the programmed HomeLink ® button. Activation will now occur for the trained device( i. e. garage door opener, gate operator, security system, entry door lock, home / office lighting, etc.). For convenience, the hand-held remote of the device may also be used at any time.
! Erasing HomeLink ® buttons s03ap070412
To erase programming from the three buttons( individual buttons cannot be erased but can be“ reprogrammed” as outlined below), follow the step noted:
Press and hold the two outer HomeLink ® buttons for at least 10 seconds. The LED indicator will change from continuously lit to rapidly flashing. Release both buttons. Do not hold for longer than 20 seconds. HomeLink ® is now ready to be programmed at any time beginning with“ Programming a New HomeLink ® button”- step 1.
! Reprogramming a Single HomeLink ® button s03ap070406
To program a previously trained button, follow these steps:
1. Press and hold the desired HomeLink ® button. DO NOT release the button.
2. The indicator light will begin to slowly flash orange after 20 seconds. The HomeLink ® button can be released at this point. Proceed with“ Programming a New HomeLink ® button”- step 3.
3. If you do not complete the programming of a new device to the button, it will revert to the previously stored programming.
! Garage Door Two-Way Communication s03ap070413
HomeLink ® has the capability of communicating with your garage door opener. HomeLink ® can receive and display“ closing” or“ opening” status messages from compatible garage door opener systems. At any time, HomeLink ® can also recall and display the last recorded status communicated by the garage door opener to indicate your garage door being“ closed” or“ opened”.
HomeLink ® has the capability of receiving this communication from the garage door opener at a range up to 820 feet( 250 m).
