66
Child Restraint Systems
! Tether anchorages s01ag070102 shown in the above illustration . For details , refer to “ Top Tether Anchorages ” FP68 .
! To install a child restraint system using lower and tether anchorages s01ag070103
WARNING
Before installing a child restraint system , be sure to confirm that the seatback is securely locked into place . Otherwise , in an accident , serious injury or death could result .
1 . Move the seatback back and forth to confirm that it is securely locked into place . – Check that the red colored unlocking marker on the lock release knob is not visible . For details , refer to “ Folding Down the Rear Seatback ” FP39 .
U . S . -spec . models
1 For right seat 2 For center seat 3 For left seat
The tether anchorages ( upper anchorages ) are provided at the locations
Canada-spec . models
2 . You will find “ ” marks at the bottoms of the rear seatback . These marks indicate the positions of the lower anchorages ( bars ).
