Combination Meter Display ( Color LCD ) 183 |
||||||||||
Audio screen : |
The audio screen shows the status of audio information . For details about the audio system , refer to the separate navigation / audio Owner ’ s Manual . |
Clock and outside temperature screen : |
This screen displays the clock and outside temperature .
NOTE
. The clock can be displayed in either 12-hour display or 24-hour display . For details , refer to “ Clock ” FP217 .
. The outside temperature indicator shows the temperature in the area around the sensor . However , the temperature may not be indicated correctly or the update may be delayed in the following conditions . – While parking or driving at low speeds
– When the outside temperature changes suddenly ( example : when going in and out of an
|
underground parking area or when passing through a tunnel )
– When starting the engine after being parked for a certain period of time
. You can set the temperature units to be displayed in Celsius ( 8C ) or Fahrenheit ( 8F ). For details , refer to “ General settings ” FP193 ( 11.6-inch display models ) or “ General settings ” FP206 ( dual 7.0-inch display models ).
Boost pressure screen :
This screen displays the boost pressure .
|
3
Instruments and Controls
|
|||||
– CONTINUED – |
