Combination Meter Display ( Color LCD ) 179 |
||||
|
NOTE
. The ECO gauge shows only an approximate indication .
. After resetting the trip meter , the average rate of fuel consumption is not shown until driving 0.6 miles ( 1 km ). Until that time , the ECO gauge does not operate .
! Clock and temperature
s03bn1202
This screen displays the clock and outside temperature .
|
NOTE
. The clock can be displayed in either 12-hour display or 24-hour display . For details , refer to “ Clock ” FP217 .
. The outside temperature indicator shows the temperature in the area around the sensor . However , the temperature may not be indicated correctly or the update may be delayed in the following conditions . – While parking or driving at low speeds
– When the outside temperature changes suddenly ( example : when going in and out of an underground parking area or when passing through a tunnel )
– When starting the engine after being parked for a certain period of time
. You can set the temperature units to be displayed in Celsius ( 8C ) or Fahrenheit ( 8F ). For details , refer to “ General settings ” FP193 ( 11.6-inch display models ) or “ General settings ” FP206 ( dual 7.0-inch display models ).
|
! Compass ( if equipped )
s03bn1203
|
The direction of the vehicle is displayed .
! Driving range on remaining fuel s03bn1204
|
3
Instruments and Controls
|
– CONTINUED – |
