5-4 . Using the driving support systems
367
■ When moving forward and a collision with a stationary object on the inner side of a turn is likely
Types of sensors �P . 341
WARNING
■ To ensure the system can operate properly
�P . 342
■ If the Parking Support Brake
function operates unnecessarily , such as at a railroad crossing
�P . 364
■ Notes when washing the vehicle
�P . 342
■ When reversing and a collision with a stationary object on the outer side of a turn is likely
■ The Parking Support Brake function ( static objects front and rear of the vehicle ) will operate when
The function will operate when the driving assist information indicator is not illuminated ( �P . 148 , 150 ) and all of the following conditions are met :
● EV system output restriction control
• The Parking Support Brake is enabled .
• The vehicle speed is approximately 9 mph ( 15 km / h ) or less .
• There is a static object in the traveling direction of the vehicle and
approximately 6 to 13 ft . ( 2 to 4 m ) away .
• The Parking Support Brake determines that a stronger-than-normal brake operation is necessary to avoid a collision .
● Brake control
• EV system output restriction control is operating .
• The Parking Support Brake determines that an immediate brake
operation is necessary to avoid a collision .
5
Driving
