2-2 . Charging
93
■ AC charging connector lock function
If the AC charging connector is locked / unlocked repeatedly , it may not work temporarily due to protect the system by AC charging system . In this case , wait for a while before connecting the AC charging connector to AC charging inlet again .
The AC charging connector lock function does not guarantee that theft of the AC charging cable will be prevented , and is not necessarily
effective for all mischiefs .
■ Security function for unlocking
If the AC charging connector is not removed within approximately 30 seconds after the vehicle is unlocked , the security function automatically locks the connector again .
■ When the AC charging connector cannot be inserted into the AC charging inlet
If the connector lock pin is extended , the connector lock is
operating .
Unlock the doors using the smart
key system or wireless remote control and unlock the AC charging connector lock and check that the
connector lock pin is not extended . unlocked and can be removed .
3 After unlocking the AC charging connector , fix the handle of the emergency release wire to the attachment .
This method is a temporary correction procedure for emergency use only . If the problem persists , have the vehicle inspected by your SUB-
ARU dealer immediately .
Do not operate the emergency release wire when the charging connector can be unlocked in the normal procedure .
2
Electric Vehicle system
■ If the AC charging connector cannot be unlocked
The AC charging connector can be unlocked by operating the emergency release wire .
1 Open the hood . ( �P . 464 ) 2 Pull the emergency release wire . The AC charging connector is
