7-3 . Do-it-yourself maintenance
483 does not blink 3 times when starting the tire inflation pressure setting procedure , the procedure may not have started . Perform the procedure again from the beginning .
●If tire inflation pressure setting procedure cannot be completed
after performing the above procedure , contact your SUBARU dealer .
WARNING
■ When setting using the current tire inflation pressure
Make sure to adjust the tire inflation pressure of each tire to the
appropriate level before performing tire pressure setting . Otherwise , the tire pressure warning light may not illuminate even if the tire inflation pressure drops or may illuminate even though the tire inflation pressure is normal .
Registering ID codes
■ When the registering ID codes
The tire pressure warning valve and transmitter is equipped with a unique ID code .
When new tire pressure warning valves and transmitters are installed , new ID codes must be registered in the tire pressure warning computer .
■ How to registration ID code
1 Park the vehicle in a safe place , wait for approximately 15 minutes .
2 Start the EV system . ( �P . 231 )
The ID code registration procedure cannot be performed while the vehicle is moving .
3 Press or of the meter control switches and select
.
4 Press or of the meter control switches and select “ Vehicle Settings ”, and then press and hold the “ OK ”.
5 Press or of the meter control switches and select “ TPWS Setting ”, and then press “ OK ”.
6 Press or of the meter control switches and select “ Tire Set Switching ”, and then press “ OK ”.
7 Press or of the meter control switches and select “ Register New Valve / ID ” and then press “ OK ”.
8 Check if the desired wheel set (“ Tire Set 1 ” or “ Tire Set 2 ”) is displayed .
ID codes will be registered to the displayed wheel set .
To change the wheel set to be registered , press or of the
meter control switches , and then select the wheel set you wish to register .
If ID codes have already been registered for that wheel set , the tire
pressure warning light will slowly blink 3 times , and a message indi-
7
Maintenance and care
