4-2 . Opening , closing and locking the doors
177 simultaneously .
When the following procedures are performed and there are no electronic keys for the vehicle within the vehicle , all of the doors will lock when the power back door is completely closed .
1 Close all of the doors except the power back door .
2 While carrying an electronic key , press the switch on the lower part of the power back door ( �P . 174 ).
A different buzzer than the normal one will sound and then the power back door will begin closing automatically . When the power back door is closed , all of the doors will lock simultaneously and operation signals will indicate that all of the doors have been locked .
The double locking system will not operate at this time .
■ Situations in which the close & lock function may not operate properly
In the following situations , the close & lock function may not operate properly :
●If the switch on the lower part
of the power back door ( �P . 174 ) is pressed by a hand which is holding an electronic key
●If the switch on the lower part
of the power back door ( �P . 174 ) is pressed when the electronic key is in a bag , etc ., that is placed on the ground
●If the switch on the lower part
of the power back door ( �P . 174 ) is pressed with the electronic key not near the vehicle .
■ When reconnecting the 12-volt battery
To enable the power back door to operate properly , close the back door manually .
■ If the back door opener is inoperative
The back door can be unlocked from the inside .
1 Remove the cover .
To prevent damage , cover the tip of the screwdriver with a rag .
2 Loose the screw and move the cover .
3 Move the lever .
4 When installing , reverse the steps listed .
■ Customization
Some functions can be customized . ( Customizable features : �P . 574 )
4
Before driving
