2-2 . Charging
113 cannot be heard due to noise occurrence during DC charging
●As the battery approaches full charge , the charging speed will decrease and it will take longer to complete charging .
●The time to complete charging may change , or charging may stop before reaching the upper limit of the charge capacity , due to
the remaining charge of the traction battery , the outside temperature , the specifications of the
charger ( stand ), etc .
●It is recommended to avoid frequent DC charging to prevent a decline in the traction battery capacity .
●Quickly move from the DC charging space for other users
after the DC charging is completed .
■ How to set the DC charging power
You can change the DC charging power limit on the multi-information display or multimedia .
● Setting operations on multi-information display
1 Press or of the meter control switches to select .
2 Press or of the meter
control switches to select “ Vehicle Settings ”, and then press and
hold .
3 Press or of the meter
control switches to select “ Charging Settings ”, and then
press .
The “ Charging Settings ” screen will be displayed .
4 Press or of the meter control switches to select “ DC charging power ”, and then press
. The “ DC charging power ” screen will be displayed .
5 Press or of the meter
control switches to select the charging power from “ MAX ”, “ 75kW ”, “ 50kW ” and then press
. * The maximum power when
charging is limited to the selected power or less .
If “ MAX ” is selected , the vehicle will be charged with the maximum power that can be charged .
● Setting operations on multimedia
1 Select . 2 Select “ Vehicle customize ”. 3 Select “ Charging ”. 4 Select “ DC charging power ”.
5 Select from “ MAX ”, “ 75kW ”, “ 50kW ”. * The maximum power when
charging is limited to the selected power or less .
If “ MAX ” is selected , the vehicle will be charged with the maximum power that can be charged .
■ Changing the “ Charging Limit ” settings
�P . 106
■ If “ Check Charging System
Close Charging Port Lid See Owner ’ s Manual ” is displayed on the multi-information display
If the system check after DC charging is not completed successfully , the EV system will not start even if the power switch is pressed while depressing the brake pedal .
Perform a system check with the following procedures .
2
Electric Vehicle system
