2-2 . Charging
109
WARNING
■ Onboard traction battery charger
The onboard traction battery charger is located in the motor compartment . Make sure to observe the following precautions regarding the onboard traction battery charger . Failure to observe these precautions may result in death or
serious injury such as burns and electric shocks .
●The onboard traction battery charger is hot during charging . Do not touch the onboard traction battery charger , as doing so
may result in burns .
●Do not disassemble , repair or modify the onboard traction battery charger . When the onboard traction battery charger needs to be repaired , consult your SUBARU dealer .
After charging
1 Unlock the doors to unlock the charging connector . ( �P . 91 )
The charging connector will be unlocked and the AC charging inlet light will illuminate when the doors
are unlocked .
2 Pull the charging connector towards you while pressing the latch release button .
If the latch release button is pressed during charging ( while the
charging indicator is illuminated ), charging will be interrupted .
2
Electric Vehicle system
NOTICE
■ When charging Do not insert the plug into the AC charging inlet . The AC charging inlet may be
damaged .
■ Using private power generator
Do not use private power generators as a power source for charging .
Doing so may make charging unstable , the voltage may be insufficient , and the charging
operation may stop .
■ Charging station
Due to the environment in which the power equipment is located , charging may be unstable due to noise , the voltage may be insufficient , and the charging operation may stop .
3 Attach the charging connector cap .
