2-2 . Charging
107
1 Press or of the meter control switches to select .
2 Press or of the meter
control switches to select “ Vehicle Settings ”, and then press and
hold .
3 Press or of the meter
control switches to select “ Charging Settings ”, and then
press .
The “ Charging Settings ” screen will be displayed .
4 Press or of the meter
control switches to select “ Charging Limit ”, and then press
.
The “ Charging Limit ” screen will be displayed .
5 Select “ Full ”, “ 90 %”, “ 80 %”, “ 70 %”, “ 60 %” or “ 50 %” and then
press .
● Setting operations on multimedia
1 Select . 2 Select “ Vehicle customize ”. 3 Select “ Charging ”. 4 Select “ Charging limit ”. 5 Select “ Full ”, “ 90 %”, “ 80 %”, “ 70 %”, “ 60 %” or “ 50 %”.
If the setting is changed during DC charging , charging may stop due to
the operation of the DC charger timer and the traction battery cannot be fully charged .
■ Protection function of AC charging inlet overheating
By installing a temperature sensor
to the AC charging inlet , prevents parts from melting when the temperature rises due to foreign matter
entering the charging connector .
When a certain temperature increase is detected , charging is stopped immediately .
After this , when the power switch is off , a message will be displayed on the multi-information display ( �P . 138 )
WARNING
■ When charging
Observe the following precautions .
Failure to do so may cause an unexpected accident , resulting in death or serious injury .
●Connect to a power source suitable for charging . ( �P . 94 )
●Check that the AC charging cable , plug and outlet are free of foreign matter .
●Before charging , check that the AC charging inlet is not deformed , damaged or corroded , and check that the inlet is free of foreign matter such as dirt , snow and ice . If there is dirt or dust in these areas , remove completely before inserting the charging
connector .
●Do not get the terminals of the AC charging inlet wet .
●Only use outlets where the plug can be securely inserted .
●Do not bundle or wind the AC charging cable while charging , as doing so may result in overheating .
●Do not touch the terminals of the charging connector and AC charging inlet with a sharp metal objects ( needles , etc .,) or hands , or short them with foreign objects .
2
Electric Vehicle system
