2-2 . Charging
103 charging-related parts is high .
■ Charging electricity
This vehicle can be charged up to approximately 7 kW .
However , depending on the used charger or AC charging cable , charging electricity may be limited .
How to use AC charging
This section explains the procedure for charging the traction battery with an AC charging cable .
When using an AC charger , make sure to check the operation instructions of the AC charger .
When the charging schedule is registered , make sure “ Charge Now ” is turned on before charging . ( �P . 122 , 126 )
NOTICE
■ When using the AC charging cable and related parts
To prevent damage to the AC charging cable and related parts , observe the following precautions .
●When interrupting or canceling
charging , remove the charging connector before removing the plug .
●When removing the AC charging cable , check that the charging connector is unlocked .
●Do not forcefully pull the charging connector cap and AC
charging inlet cap .
●Do not apply a vibration to the charging connector while charging . Charging may be stopped .
●Do not insert anything but the charging connector into the AC charging inlet .
2
Electric Vehicle system
