372
STARTING AND OPERATING
even if the headlights are turned on, the brightness of the BSW / RCTW approach indicator light will not be reduced. For details about the illumination brightness control dial, refer to“ Illumination Brightness Control” FP161.
BSW / RCTW approach warning buzzer( only when reversing) s07bm0302
A warning buzzer sounds along with flashing of the BSW / RCTW approach indicator light to warn the driver of dangers.
The setting of the warning buzzer volume can be changed by operating the center information display. For details, refer to“ Sound” FP200.
Safety tips regarding the BSW / RCTW approach indicator light / warning buzzer s07bm0303
. In the following cases, operation of the BSW / RCTW approach indicator light and the warning buzzer may be delayed or the system may fail to issue these warnings.
– When a vehicle moves to the neighboring lane from a lane next to the neighboring lane
– When driving on a steep incline or on repeated sharp uphill and downhill grades
– When going beyond a pass
– When both your vehicle and a vehicle driving on a neighboring lane are driving on the far side of each lane.
– When several narrowly-spaced vehicles are approaching in a row
– In low radius bends( tight bends or when making turns at an intersection)
– When there is a difference in height between your lane and the neighboring lane
– Immediately after the BSW / RCTW is activated by touching“ Blind Spot Warning( BSW)/ Rear Cross Traffic Warning( RCTW)”
– Immediately after the select lever is shifted to the“ R” position
– When extremely heavy cargo is loaded in the cargo area
. During reversing, operation of the BSW / RCTW approach indicator light and the warning buzzer may be delayed or the system may fail to issue these warnings under the following conditions.
– When backing out of an angled parking space
– When a large-sized vehicle is parked next to your vehicle( That vehicle prevents the propagation of radar waves.)
– When reversing on sloped roads – When reversing at a high speed
S _ 703176-W
. The BSW / RCTW approach indicator light may illuminate when driving close to solid objects on the road or road side( such as guardrails, tunnels and sidewalls).
. When turning at an intersection in urban areas, or a multilane intersection, the BSW / RCTW approach indicator light may flash.
. If a building or a wall exists in the reversing direction, the BSW / RCTW approach indicator light may flash and the warning buzzer may sound.
