INSTRUMENTS AND CONTROLS
– The shown items are a very far distance away.
– The environmental conditions are very dark.
Compass calibration:
If the compass appears inaccurate, recalibrate the compass.
To operate the compass feature s03ap1107
Left button Center button Right button
S _ 308178-W
Press any of the left, center or right buttons to display the main menu. Select compass mode using the left button.
NOTE
The main menu cannot be displayed on the display while the select lever is in a position other than the“ P” position.
S _ 308186-W
1. Select“ CALIBRATE” using the right button.
2. To start the compass calibration, press the center button.
3. Select“ Continue” using the center button.
To turn the compass feature on / off:
S _ 308187-W
4. Select your current location in the display using the left button.
5. Select“ Continue” using the center button.
6. Once“ C” appears in the display, slowly drive the vehicle in circles until compass is calibrated.
Compass
S _ 308185-W
Select“ ON” or“ OFF” using the center button.
HomeLink ® Wireless Control System s03ap1108
The HomeLink ® Wireless Control System provides a convenient way to replace up to three hand-held radio-frequency remotes used to activate devices such as
