INSTRUMENTS AND CONTROLS 191
Mark Name Page
RAB warning indicator 183
Proximity Warning Detection OFF indicator
184
BASIC SCREENS s03bn06
By operating the or switch on the steering wheel, you can change the screen that is always displayed.
ECO gauge:
BSW / RCTW warning indicator
BSW / RCTW OFF indicator
183
183
3
Hill descent control indicator light
Auto Start Stop warning light( yellow)
183
181
Auto Start Stop indicator light( green)
Auto Start Stop OFF indicator light
Auto Start Stop No Activity Detected indicator light
Windshield washer fluid warning light
Distraction Mitigation System operation indicator light( green)
Distraction Mitigation System warning light( yellow)
Distraction Mitigation System OFF indicator light
Distraction Mitigation System temporary stop indicator light
Icy road surface warning light
Electric damper system warning light( if equipped)
Front Cross Traffic Braking warning indicator( if equipped)
Front Cross Traffic Braking OFF indicator( if equipped)
182
181
182
174
184
184
184
184
183
182
184
184
S _ 308382-W
The ECO gauge shows the difference between the average rate of fuel consumption since the trip meter was last reset and the current rate of fuel consumption.
The ECO gauge indicates the current fuel efficiency as shown in the following chart.
Displayed unit
Needle position
“+” side“ −” side MPG Better Poorer l / 100km Poorer Better
NOTE
. The ECO gauge shows only an approximate indication.
. After resetting the trip meter, the average rate of fuel consumption is not shown until driving for approximately 10 seconds. Until that time, the ECO gauge does not operate.
– CONTINUED –
