Child Restraint Systems 67 |
|||||||||
|
11.6-inch display models: Front passenger’ s frontal airbag ON indicator light
: Front passenger’ s frontal airbag OFF indicator light
|
When front passenger’ s frontal airbag OFF indicator light is illuminated: Only forward facing child restraint systems can be installed on the front passenger’ s seat. When front passenger’ s frontal airbag ON indicator light is illuminated: Child restraint systems cannot be installed on the front passenger’ s seat. Install the child restraint system on the rear seats. For more details, refer to“ SUBARU Advanced Frontal Airbag System, SRS Seat Cushion Airbag, SRS Side Airbag and SRS Curtain |
Airbag” FP91.
5. Check that the child restraint system does not contact the head restraint. If the child restraint system does make contact with the head restraint, raise the head restraint to the extended position. If the child restraint system still makes contact, remove the head restraint. For details, refer to“ Head Restraint Adjustment” FP38.
& Installing Child Restraint Systems with ALR / ELR Seatbelt s01ag04
CAUTION
|
. When you install a child restraint system, follow the manufacturer’ s instructions supplied with it. After installing the child restraint system, check to ensure that it is held securely in position. If it is not held tight and secure, the danger of your child suffering personal injury in the event of an accident may be increased.
. When installing a child restraint system in the rear center seating position, set both seatbacks to the original position. Otherwise, the child restraint system cannot
|
be securely restrained, which may result in death or serious injuries in the event of sudden stop, sudden steering maneuver or an accident.
! Installing a rearward facing child restraint system s01ag0401
WARNING
. NEVER INSTALL A REARWARD FACING CHILD RESTRAINT SYS- TEM ON THE FRONT PASSEN- GER’ S SEAT. DOING SO RISKS SERIOUS INJURY OR DEATH TO THE CHILD BY PLACING THE CHILD’ S HEAD TOO CLOSE TO THE SRS AIRBAG.
. Before installing a child restraint system, be sure to confirm that the seatback is securely locked into place. Otherwise, in an accident, serious injury or death could result.
|
1. Place the child restraint system in the rear seating position.
– CONTINUED –
|
1
Seat, Seatbelt and SRS Airbags
|
