66
Child Restraint Systems
& When Installing the Forward Facing Child Restraint System on the Front Passenger ’ s Seat s01ag15
that uses tether straps , do not install it on the front passenger ’ s seat .
Only forward facing child restraint systems ( including booster seats ) can be installed on this seat and should only be installed when it is unavoidable . When you install a forward facing child restraint system to the front passenger ’ s seat , perform the following procedure .
1 . Adjust the front passenger ’ s seat as illustrated .
2 . Install the child restraint system to the front passenger ’ s seat . Refer to “ Installing a forward facing child restraint system ” FP69 .
3 . Place and secure the child in the child restraint system .
4 . Check that the front passenger ’ s frontal airbag ON / OFF indicator light status meets the requirements of your child restraint system .
WARNING
. NEVER INSTALL A REARWARD FACING CHILD RESTRAINT SYS- TEM ON THE FRONT PASSEN- GER ’ S SEAT . DOING SO RISKS SERIOUS INJURY OR DEATH TO THE CHILD BY PLACING THE CHILD ’ S HEAD TOO CLOSE TO THE SRS AIRBAG .
. The front passenger ’ s seat is not equipped with tether anchorages . Therefore , when installing a child restraint system
A B
C
Seat position : Rearmost as possible Seat cushion height ( if equipped ): Uppermost
Seatback : Upright
Dual 7.0-inch display models
: Front passenger ’ s frontal airbag ON indicator light
: Front passenger ’ s frontal airbag OFF indicator light
