468
Loading Your Vehicle
carrying load of the cargo, roof crossbars and carrying attachments does not exceed 220 lbs( 100 kg). Overloading may cause damage to the vehicle. Read the manufacturer’ s instructions and pay attention to not exceed the load limit of the parts.
. For cargo carrying purposes, the roof rails must be used together with the SUBARU recommended roof crossbars and any appropriate carrying attachment that may be needed. The roof rails must never be used alone to carry cargo. Otherwise, damage to the roof or paint, or a dangerous road hazard due to loss of cargo could result.
NOTE
Remember that the vehicle’ s center of gravity is altered with the weight of the load on the roof, thus affecting driving characteristics.
Drive carefully. Avoid rapid starts, hard cornering and abrupt stops. Crosswind effects will be increased.
! Rope hooks( attached to the roof rails) s08aj1501
1 Rope hooks 2 Covers
CAUTION
. When you use the rope hooks, always secure the rope at all four hook points.
. The maximum load capacity is 176 lbs( 80 kg) per hook.
. The cover cannot be removed.
. Do not tighten the rope excessively. Otherwise, it may lead to damage to the vehicle body or cargo.
. Check that the rope is not loose before driving the vehicle.
. When you use the rope hooks, never exceed the maximum load limit.
& Roof Tent( Subaru Outback Wilderness) s08aj14
WARNING
Adding weight to the vehicle’ s roof can adversely affect handling, braking, and rollover resistance. The vehicle must never be driven with a total roof rail load in excess of 220 lbs( 100 kg).
