412
Rear View Camera
Otherwise, it may cause an accident or injury.
. The actual position may be different from the indication of the help lines.
. Differences may occur due to the number of passengers or the loaded cargo.
. When the vehicle is on a slope or inclined against the road, the indication is different from the actual position.
! When there is an upward slope at the back s07br030101
! When there is a downward slope at the back s07br030102
NOTE
When“ Steering Angle Lines” is off, the dynamic guidelines will be disappear on the center information display. To turn the dynamic guidelines on and off, refer to“ General settings” FP227( 11.6-inch display models) or“ General settings” FP245( dual 7.0-inch display models).
! Difference between screen image and actual road s07br0301
The distance markers show the distance for a level road when the vehicle is not loaded. It may be different from the actual distance depending on the loading conditions or road conditions.
1 3 ft( 1 m)
The distance on the screen looks farther than the actual distance.
1 3 ft( 1 m)
The distance on the screen looks nearer than the actual distance.
NOTE
When cargo is loaded, the rear view distance on the screen looks farther than the actual distance as in an upward slope.
