Front View Monitor
& How to Access the Front View Monitor s07bq01
1 Front view monitor switch
To change over to the camera screen, make sure the ignition switch is in the“ ON” position, then press the front view monitor switch under the following conditions.
. The vehicle speed is below 12 mph( 20 km / h).
. The select lever is in except“ R”.
NOTE
The screen will change over to the rear view image when the select lever is moved to“ R”. Refer to“ Rear View Camera” FP408.
& How to Cancel the Front View Monitor s07bq02
! Manual cancellation s07bq0201
The Front View Monitor will be canceled by either of the following operations.
. Press the front view monitor switch again.
. Touch( car settings icon).. Touch( HOME).. Touch( driver profiles icon).! Automatic cancellation s07bq0202
If any of the following conditions are met, the Front View Monitor is canceled automatically.
After accessing the Front View Monitor by pressing the front view monitor switch:
. Approximately 3 minutes have passed since the last operation.
. The vehicle speed becomes 13 mph( 20 km / h) or higher.
. The select lever is shifted to the“ P” position.
. Pulling up the parking brake switch with the brake pedal depressed to apply the parking brake.
& Range of Image on Screen s07bq03
A Traffic intersection with a poor visibility view
B Parking facing a wall 1 Range of displayed image
2 Obstacles( e. g., buildings, fences or other vehicles)
