Front View Monitor 405 |
|||||
|
stopped by the Auto Start Stop system.
When this occurs, the buzzer will stop sounding when the following operations are performed.
. The engine is restarted by normal operation.( Refer to“ Preparing to Drive” FP360.)
. The ignition switch is turned to the“ LOCK”/“ OFF” position.
! Display of warning messages s07bh0302
If a warning message is displayed on the combination meter display( color LCD) while driving, a malfunction may have occurred in the Auto Start Stop system. In this case, the Auto Start Stop warning light will illuminate. We recommend that you have your vehicle inspected at a SUBARU dealer as soon as possible.
|
7-18. Front View Monitor( If Equipped) |
s07bq
The image from the camera mounted inside the front grille is displayed in the center information display.
WARNING
. Never rely on only the Front View Monitor when driving the vehicle. The image on the monitor screen may be different from the actual situation. If you drive the vehicle by viewing only the monitor image, a collision or an unexpected accident may occur. When driving the vehicle, always check the traffic around the vehicle directly
|
with your eyes and the mirrors.
. Always operate the vehicle as you would without the Front View Monitor.
. Do not use the Front View Monitor in the following situations.
– You are driving on a dirt road or a road covered in snow.
– The camera malfunctions( e. g. the lens or bracket is broken).
. If the outside temperature is low, the monitor screen may become dark or the image may become dim. In particular, the image of a moving object may be distorted or disappear from the screen. You must always check the traffic around the vehicle directly with your eyes when driving it.
NOTE
If there is a malfunction on the center information display, refer to“ Malfunctions of the Center Information Display” FP505.
|
7
Starting and Operating
|
|
– CONTINUED – |
