Continuously Variable Transmission 375 |
|||||||||
|
to pass a vehicle in front when driving on an uphill slope while towing.
. The continuously variable transmission is a chain type system that provides superior transmission efficiency for maximum fuel economy. At times, depending on varying driving conditions, a chain operating noise may be heard that is characteristic of this type of system.
. Place the shift boot to the original position after it is lifted. If the select lever is operated with the shift boot in the rolled up position, the shift boot may have tension and it may disturb the select lever operation.
|
& Select Lever |
1 Select lever button |
s07bg01 |
: With the brake pedal depressed, shift while pressing the select lever button in
: Shift while pressing the select lever button in
: Shift without pressing the select lever button
The select lever has four positions,“ P”,“ R”,“ N”,“ D” and also has a manual gate for using the manual mode.
NOTE
. For some models, to protect the engine while the select lever is in the“ P” or“ N” position, the engine is controlled so that the engine speed may not become too high even if the accelerator pedal is depressed hard.
|
7
Starting and Operating
|
||||
– CONTINUED – |
