. Do not use more than one floor mat. |
Retaining pins are located on the driver’ s side floor.
The floor mat should be properly secured using the built-in grommets, by placing the grommets over the pins and pushing them downward.
|
6-13. Lifting Cargo Cover( Outback / Subaru Outback Wilderness – If Equipped)
s06ak
The Lifting Cargo Cover is provided to cover the cargo area and to protect its contents from direct sunlight.
The cover also has the practicability of its easy lift-up function, eliminating the need to rewind the cover all the way when accessing the cargo.
This cover can be detached to make room for additional cargo.
|
& To Install the Cover Housing s06ak05 |
1. Insert the left side cover housing end into the retainer, then insert the right cover housing end into the right retainer. Make sure both ends are clicked into the retainers.
NOTE
If the label on the cover housing is placed on the top, the cover housing will be installed in reverse and it will not be affixed to the vehicle body.
|
6
Interior Equipment
|
|||||
1 Cargo area cover 2 Cover housing 3 Front cover 4 Front cover rod |
||||||||||
– CONTINUED – |
