Center Information Display( CID) 245 |
|||||||||
|
. You can set the temperature units to be displayed in Celsius( 8C) or Fahrenheit( 8F). For details, refer to“ General settings” FP245.
. The clock can be shown in either 12- hour display or 24-hour display. For details about the setting, refer to“ General settings” FP245.
. Touch the clock on the status bar to display the clock setting screen. Refer to“ Clock” FP257.
! Upper display s03bs060902
For details about items, refer to“ Setting of the upper display” FP245.
For details about the following menu, refer to the separate navigation / audio Owner’ s Manual.
. Radio. Media. Phone. Apps. Add Shortcut
! Lower display s03bs060903
For details about the setting items, refer to“ Setting of the lower display” FP248.
If this screen changes to the climate control screen, refer to“ Dual 7.0-Inch Display Models” FP310.
|
! Climate control screen
s03bs060904
|
1 Driver’ s seat heater icon( if equipped) 2 Set temperature indicator 3 Climate control mode 4 Airflow mode 5 Air inlet selection 6 Air conditioner ON indicator
7 Front passenger’ s seat heater icon( if equipped)
8 Customizable icon 9 Fan speed control 10 Climate control ON / OFF icon
When operating the climate control system, the main screen switches to the climate control screen. For details about climate control operation, refer to“ Climate Control Panel” FP309.
|
! Setting of the upper display s03bs0602
In this Owner’ s Manual, the settings of the“ General” menu will be explained. For details about other items, refer to the separate navigation / audio Owner’ s Manual.
|
! General settings s03bs060204
The“ General” menu is used to set the display, language and time.
1. Press( HOME).
|
2. Touch( Settings). 3.?“ General” 4. Select the preferred menu. |
3
Instruments and Controls
|
|||
– CONTINUED – |
